Camera

Sensor

1/3" progressive scan CMOS

Effective pixels

1080P (1080*1920）

Total pixels

2.0MP

Lens

10X optical zoom

3D NR

Support

Iris

F1.6~F1.8

Min. illumination

Color: 0.5Lux \  B/W: 0.05Lux

BLC

Support

WB

Indoor/Outdoor/Auto/Manual

D/N

IR-CUT

S/N Ratio

≥50dB

Dome

Pan range

360°continuous rotation

Tilt range

0°~93°  auto flip 180°

Pan speed

0.02~50°/S

Tilt speed

0.02~30°/S

Preset Points

220

Guard Tours

3 groups

Guard Points

Max.16 points, dwell time user selectable

Operating temperature

Indoor:0ºC～+40ºC

Operation menu

English

Pan and Tilt position display

Support

Humidity

≤95% Non Condensing

Power

 DC12V 2A

Consumption

≤20W

Lightning Protection

Transient voltage 6000V

Video interface output

AHD/TVI/CVI/CVBS

Communication mode

RS485 (+/-)

Related validation

IP66,CE,FCC,RoHs

IR parameters

Auto Control IR LED

PWM

LEDs

Array 42Mil

IR distance

Up to 50 meters

Support ambient light detection

IR illumination on 1-15 grades selectable;
